3 iLO Service Port
4 USB 3.0 port
Serial number/iLO information pull tab
The serial number/iLO information pull tab is double-sided. One side shows the server serial number and
the QR code labels. The other side shows the default iLO account information.
Use a mobile device to scan the QR code label to display the server mobile product page (http://
www.hpe.com/qref/dl180gen10). This page contains links to server setup information, spare part
numbers, QuickSpecs, troubleshooting resources, and other useful product links.
Front panel LEDs and buttons
• Front panel LEDs and buttons in an LFF chassis
• Front panel LEDs and buttons in an SFF chassis
Item Description Status
1 UID button/LED
Solid blue = Activated Flashing blue:
• 1 flash per second = Remote management or firmware
upgrade in progress
• 4 flashes per second = iLO manual reboot sequence
initiated
• 8 flashes per second = iLO manual reboot sequence in
progress
Off = Deactivated
Table Continued
Component identification 105

HP HPE ProLiant DL180 Gen10 Specifications

General

Processor Sockets	2
Memory Slots	16 DIMM slots
Expansion Slots	Up to 6 PCIe 3.0 slots
Form Factor	2U Rack
Management	HPE iLO 5
Processor	Intel Xeon Scalable processors
Storage	Up to 12 LFF or 24 SFF drives
RAID Support	HPE Smart Array S100i SR Gen10
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Network Controller	Optional FlexibleLOM or stand-up card
