17 Front I/O cable connector
18 Fan connector 6
19 Fan connector 5
20 Fan connector 4
21 Fan connector (Reserved)
22 Fan connector 3
23 Fan connector 2
24 Fan connector 1
25 Smart Storage Battery connector
26 Chassis Intrusion Detection connector
27 Drive backplane power connector
28 GPU/rear drive power connector
29 Non-hot-plug power supply connector
30 System battery
31 Internal USB 3.0 port
1
If the memory card connected to the microSD slot is not visible in Windows Device Manager, in the menu bar, click
View > Show hidden device.
System maintenance switch descriptions
Position Default Function
S1
1
Off
Off = iLO security is enabled.
On = iLO security is disabled.
S2 Off Reserved
S3 Off Reserved
S4 Off Reserved
S5
1
Off
Off = Power-on password is enabled.
On = Power-on password is disabled.
S6
1
,
2
,
3
Off
Off = No function
On = Restore default manufacturing settings
S7 Off Reserved
S8 — Reserved
S9 — Reserved
S10 — Reserved
S11 — Reserved
S12 — Reserved
116 Component identification
