Removing and replacing the secondary riser cage blank
Prerequisites
T-15 Torx screwdriver
Procedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
• Extend the server from the rack.
• Remove the server from the rack.
4. Remove the access panel.
5. Remove the secondary riser cage blank.
Removal and replacement procedures 51
