Prerequisites
T-15 Torx screwdriver
Procedure
1. Power down the server.
2. Do one of the following:
• Extend the server from the rack.
• Remove the server from the rack.
3. Open or unlock the locking latch, slide the access panel to the rear of the chassis, and remove the
access panel.
Installing the access panel
Prerequisites
• T-15 Torx screwdriver
• All internal cables must be connected and secured with clips.
Procedure
1. Place the access panel on top of the server with the latch open.
Allow the panel to extend past the rear of the server approximately 1.25 cm (0.5 in).
2. Push down on the latch. The access panel slides to a closed position.
3. Tighten the security screw on the latch.
Removal and replacement procedures 35
