Cable routing: Smart Storage Battery
Cable routing: Optical drive
SFF
Color Description
Orange Optical drive signal cable to SATA port 5
Blue Optical drive power cable
Yellow Optical drive power cable
LFF
140 Cabling

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP HPE ProLiant DL180 Gen10 and is the answer not in the manual?

HP HPE ProLiant DL180 Gen10 Specifications

General IconGeneral
Processor Sockets2
Memory Slots16 DIMM slots
Expansion SlotsUp to 6 PCIe 3.0 slots
Form Factor2U Rack
ManagementHPE iLO 5
ProcessorIntel Xeon Scalable processors
StorageUp to 12 LFF or 24 SFF drives
RAID SupportHPE Smart Array S100i SR Gen10
Operating System SupportWindows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Network ControllerOptional FlexibleLOM or stand-up card
