Chapter 6
109
6 Specifications
This chapter provides the power requirements, physical requirements, and hardware specifications required
for normal operation of the HP Integrity rx1620.
NOTE For information on operating conditions (environmental requirements), see the hp Integrity
rx1620 Site Preparation Guide included on the HP Server Documentation CD-ROM, or posted
under the rx1620 Server at http://docs.hp.com.
Hardware Specifications
Table 6-1 Hardware Specifications
Micro-processors Intel® Itanium® (up to 2 processors).
1.3 GHz 3 MB, 1.5 GHz 3 MB.
Memory Supports up to eight Double Data Rate (DDR) registered ECC Memory, in PC1600
DIMMs. Supported DDR DIMM sizes: 128MB, 256MB, 513MB, 1GB, and 2GB.
Requires DIMMs to be added in pairs of equal capacity.
SCSI Integrated Ultra-3 SCSI dual channel controller; 80 MB/s transfer rate with one
internal 68-pin connector (channel A) and one external 68-pin connector (channel
B).
LAN Two 10Mb/100Mb/1Gb LAN (RJ-45) fast ethernet controller; with Wake-on-LAN
enabled/disabled via BIOS setup.
PCI Slots Two 64-bit PCI-X slots, 133 MHz, 3.3V slots. One full slot and one half slot.
Core I/O One serial port, 2 USB 2.0 ports, 2 PCI-X slots, 2 SCSI channels and 1 IDE bus.
DVD-ROM IDE interface; 48x speed.
Mass Storage Maximum internal storage: two 146GB, 10K RPM drives.
External Storage Optional.
Power Supply 460W power supply.
