Chapter 4

Utilities

Specifying SCSI Parameters

The following SCSI parameters may be configured for the SCSI board:

• SCSI ID (SCSI initiator ID)

• Maximum data transfer rate (SCSI rate)

•Bus width

• Whether the HBA is bootable (driver support)

• Avoid bus resets (secondary cluster server)

Using the SCSI Setup Utility

Step 1. At the EFI shell prompt, type this command to map the parameters for all PCI cards installed in

the system:

info io

A list of all the devices that are installed in the hp Integrity rx1620 Server and managed by EFI

drivers is displayed. The output may look like this:

Seg Bus Dev Fnc Vendor Device Slot

# # # # ID ID # Path

--- --- --- --- ------ ------ --- -----------

00 00 01 00 0x1033 0x0035 XX Acpi(HWP0002,0)/Pci(1|0)

00 00 01 01 0x1033 0x0035 XX Acpi(HWP0002,0)/Pci(1|1)

00 00 01 02 0x1033 0x00E0 XX Acpi(HWP0002,0)/Pci(1|2)

00 00 02 00 0x1095 0x0649 XX Acpi(HWP0002,0)/Pci(2|0)

00 00 03 00 0x8086 0x1229 XX Acpi(HWP0002,0)/Pci(3|0)

00 20 01 00 0x1000 0x0030 XX Acpi(HWP0002,100)/Pci(1|0)

00 20 01 01 0x1000 0x0030 XX Acpi(HWP0002,100)/Pci(1|1)

00 20 02 00 0x14E4 0x1645 XX Acpi(HWP0002,100)/Pci(2|0)

00 40 01 00 0x1000 0x0021 02 Acpi(HWP0002,200)/Pci(1|0)

00 40 01 01 0x1000 0x0021 02 Acpi(HWP0002,200)/Pci(1|1)

00 80 01 00 0x14E4 0x1645 01 Acpi(HWP0002,400)/Pci(1|0)

00 E0 01 00 0x103C 0x1290 XX Acpi(HWP0002,700)/Pci(1|0)

00 E0 01 01 0x103C 0x1048 XX Acpi(HWP0002,700)/Pci(1|1)

00 E0 02 00 0x1002 0x5159 XX Acpi(HWP0002,700)/Pci(2|0)
