HP Integrity rx1620 User Manual

Chapter 2
Controls, Ports and Indicators
Rear Panel
19
10/100/1000 base-T ethernet LAN B 1Gb Connector
The rear panel 10/100/1000 base-T ethernet LAN B 1Gb connector has the following status and activity
LEDs.
Figure 2-7 10/100/1000 base-T ethernet LAN B 1Gb Connector LEDs
Table 2-6 10/100/1000 base-T ethernet LAN B 1Gb Connector LEDs
Link LED Output
Activity Blinking Orange
Link w/no activity Solid Orange
No link Off
Link LED
LED
(not used)
