HP Integrity rx1620 User Manual

Chapter 2
Controls, Ports and Indicators
Additional Controls and Indicators
15
Additional Controls and Indicators
The hp Integrity rx1620 Server can have up to two low-voltage differential (LVD), 3.5 inch form factor hard
disk drives installed. These hard disk drives have LEDs that provide status and activity information.
Hard Disk Drive Indicators
The hard disk drives have two LEDs per drive, as described below.
• Activity LED—The Drive Activity LED is green and indicates disk drive activity. This LED is directly
controlled by the disk drive and turns on when a drive is accessed.
• Status LED—The Drive Status LED is not used on the hp Integrity rx1620.
Figure 2-3 Hard Disk Drive LED Indicators
Table 2-2 Hard Disk Drive LED Definitions
LED Activity Description
Status LED None Not Used
Activity LED Flashing green Drive access under hard drive control
Status LED
(not used)
Activity LED
