HP ProCurve Switch 2650 User Manual

6-14
Configuring and Monitoring Port Security
Port Security Command Options and Operation
Note You can reduce the address limit below the number of currently authorized
addresses on a port. This enables you to subsequently remove a device from
the “Authorized” list without opening the possibility for an unwanted device
to automatically become authorized.
For example, suppose port A1 is configured as shown below and you want to
remove 0c0090-123456 from the Authorized Address list:
Figure 6-8. Example of Two Authorized Addresses on Port A1
The following command serves this purpose by removing 0c0090-123456 and
reducing the Address Limit to 1:
HPswitch(config)# port-security a1 address-limit 1
HPswitch(config)# no port-security a1 mac-address 0c0090-
123456
The above command sequence results in the following configuration for port
A1:
Figure 6-9. Example of Port A1 After Removing One MAC Address
When removing 0c0090-123456, first
reduce the Address Limit by 1 to prevent
the port from automatically adding another
device that it detects on the network.
!FishSecurity.book Page 14 Thursday, October 10, 2002 9:19 PM

HP ProCurve Switch 2650 Specifications

General

Switching Capacity	13.6 Gbps
Forwarding Rate	10.1 Mpps
Layer	Layer 2
Form Factor	Rack-mountable
Flash Memory	8 MB
Jumbo Frame Support	Yes
Power Supply	Internal
Management	Web, CLI, SNMP
Features	VLAN support, IGMP snooping, QoS
Operating Temperature	0°C to 45°C (32°F to 113°F)
Operating Humidity	15% to 95% (non-condensing)
Ports	48 x 10/100
MAC Address Table Size	8, 000 entries
