Server Component Identification 105
PCI Riser Cage LED
CAUTION: To prevent damage to the server or expansion
boards, power down the server and remove all AC power cords before
removing or installing the PCI riser cage.
Status
On = AC power connected
Off = AC power disconnected
Remote Management Connector
The 30-pin remote management connector, located on the PCI riser cage, is used
to cable the Remote Insight Lights-Out Edition II option. For more information,
refer to "RILOE II Cabling" or the Remote Insight Lights-Out Edition II User
Guide on the Documentation CD.
