98 HP ProLiant DL380 Generation 3 Server Maintenance and Service Guide
System LED and
Color
Internal Health
LED Color
Status
Fan (Amber) Amber Redundant fan has failed.
Red The minimum fan requirements are not being met. One
or more fans have failed or are missing.
SCSI configuration
error (Amber)
Red SCSI cabling or terminator configuration is incorrect for
SCSI backplane.
SCSI Backplane Components
