Hot-Plug SCSI Hard Drive LED Combinations
Activity
LED (1)
Online
LED (2)
Fault
LED (3)
Interpretation
On, off,
or
blinking
On or off Blinking A predictive failure alert has been received for this drive.
Replace the drive as soon as possible.
On, off,
or
blinking
On Off The drive is online and is configured as part of an array.
If the array is configured for fault tolerance and all other drives in
the array are online, and a predictive failure alert is received or a
drive capacity upgrade is in progress, you may replace the drive
online.
On Blinking Off The drive is rebuilding or undergoing capacity expansion.
Do not remove the drive. Removing a drive may terminate the
current operation and cause data loss.
On Off Off The drive is being accessed, but (1) it is not configured as part of
an array; (2) it is a replacement drive and rebuild has not yet
started; or (3) it is spinning up during the POST sequence.
Do not remove the drive. Removing a drive may cause data
loss.
Blinking Blinking Blinking Either (1) the drive is part of an array being selected by an array
configuration utility, or (2) Drive Identification has been selected in
Insight Manager.
Do not remove the drive. Removing a drive may cause data
loss in non-fault-tolerant configurations.
Off Off On The drive has failed and been placed offline.
You may replace the drive.
Off Off Off Either (1) the drive is not configured as part of an array; (2) the
drive is configured as part of an array, but a powered-up controller
is not accessing the drive; or (3) the drive is configured as an
online spare.
If the drive is connected to an array controller, you may replace
the drive online.
