36 HP ProLiant DL380 Generation 3 Server Maintenance and Service Guide
Expansion Slot Cover (Slots 2 and 3)
To remove the component:
1. Extend or remove the server from the rack ("Extending the Server from the
Rack" on page 18, "Removing the Server from the Rack" on page 21).
2. Remove the access panel ("Removing the Access Panel" on page 21).
3. Open the PCI riser cage door.
CAUTION: To prevent improper cooling and thermal damage,
do not operate the server unless all PCI slots have either an expansion
slot cover or an expansion board installed.
4. Press the PCI Hot Plug button to remove power from the slot. When the
green power LED on the slot stops flashing, power has been removed from
the slot.
