Removal and Replacement Procedures 59
4. Open the processor retaining bracket.
CAUTION: To prevent thermal instability and damage to the
server, do not separate the processor from the heatsink. The processor,
heatsink, and retaining clip make up a single assembly.
5. Remove the processor and heatsink assembly.
