HP ProLiant ML150

Parts Identification and Parts List
Exploded View and Parts List – Bezels and Drives
Table 6-1: Parts List – Bezels and Drives
Item No. Description Part Number
1 Upper Bezel 344694-003
2 Flexible Disk Drive 344703-003
3a CD-ROM Drive 344702-003
3b DVD-ROM Drive 344701-003
4a 36GB 10K Cold Swap Drive Ultra320 344688-003
4b 73GB 10K Cold Swap Drive Ultra320 344690-003
4c 144GB 10K Cold Swap Drive Ultra320 344692-003
5 Cold Swap Lower Bezel 344696-003
6 Filler Panel 344683-003
7a 36GB 10K Hot Swap Drive Ultra320 344687-003
7b 73GB 10K Hot Swap Drive Ultra320 344689-003
7c 144GB 10K Hot Swap Drive Ultra320 344691-003
8 Hot Swap Hard Drive Carrier 344684-003
9 Hot Swap Lower Bezel 344695-003
