HP ProLiant ML150

Installing and Configuring
Removing a Processor and Heatsink
Use this procedure to remove a processor and its heatsink. The heatsink with cooling fan
must be removed first, before removing the processor.
CAUTION: Always wear a wrist-strap and use a static-dissipating work surface connected to
the chassis when handling components. Be sure the metal of the wrist strap contacts your
skin.
Before you touch the processor to remove it, touch a grounded, unpainted metal surface on
the HP server to discharge static electricity.
1. Disconnect the cooling fan connector from its respective cooling fan connector on the
system board.
2. Open the locking levers on both brackets. Refer to Figure 2-18.
3. Lift the heatsink away from the processor and out of the server.
4. Open the ZIF lever to allow removal of the processor. Refer to Figure 2-15.
5. Grasp the processor by its edges, lift it out of the socket, and place it on a static-
dissipating work surface or into an anti-static bag.
Accessory Boards
The system board in the HP ProLiant ML150 server provides five PCI slots (slot 1 through
slot 5), with one 32-bit slot and four 64-bit slots. All PCI slots accept full-length accessory
boards.
Tested PCI Boards.
For a list of tested PCI boards, check for compatibility in the Hardware Tested Products list
for the HP ProLiant ML150 server under the Service and Support topic for the specific NOS
used in the server on the HP website at:
http://www.hp.com
CAUTION: Some accessory board outputs may exceed U.S. National Electrical code (NFPA
70) Class 2 or limited power source limits and must use appropriate interconnecting cabling in
accordance with the National Electrical Code.
