HP ProLiant ML150 User Manual

1
Controls and Indicators
This chapter describes the controls, ports, and indicators on the front and rear of the HP
ProLiant ML150 server.
Controls and Indicators Location
Please refer to your HP ProLiant ML150 server Installation Sheet for the locations of the
controls and indicators on the front and rear panels.
Front LED Indicators
Table 1-1: Control Panel Switches and Indicators
Control/Indicator Description
Power On/Off Switch
The power switch turns the HP server power On or Off. If sleep
states are available, it also transitions between Power On and
sleep states. Sleep states are NOS dependent and only available
if your NOS supports power management based on the ACPI
(Advanced Configuration and Power Interface) standard. Refer to
“Applying Power to the HP Server” and “Sleep States (ACPI)”
later in this chapter.
Power LED
• Steady green indicates the server is operating normally.
• Off (unlit) indicates the server is powered off or in standby
mode.
Disk Activity LED
•
Flashing amber indicates SCSI disk drive activity.
•
Off (unlit) indicates inactive operation.
LAN Link LED
•
Flashing green indicates a valid 100/1000 Mbps LAN link.
•
Off (unlit) indicates the server is not connected to LAN.
HP ProLiant ML150 Server Operations and Maintenance Guide 1-1
HP CONFIDENTIAL Codename: Stone Soup Part Number: 343329-001 Last Saved On: 8/14/03 10:01 AM

HP ProLiant ML150 Specifications

General

Tcase	72.8 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2603V3
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor codename	Haswell
Motherboard chipset	Intel C610
Number of QPI links	2
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	51 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID support	-
HDD interface	Serial ATA
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	16x DIMM
Internal memory	4 GB
Memory clock speed	2133 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card family	NVIDIA
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Chassis type	Rack (1U)
Power supply	550 W
Processor ARK ID	83349
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0

Weight and Dimensions

Depth	620 mm
Width	200 mm
Height	432.6 mm
Weight	22230 g
