HP ProLiant ML150 User Manual

About This Guide
This maintenance and service guide can be used for reference when servicing HP ProLiant
ML150 server.
WARNING: To reduce the risk of personal injury from electric shock and hazardous
energy levels, only authorized service technicians should attempt to repair this
equipment. Improper repairs can create conditions that are hazardous.
Audience Assumptions
This guide is for service technicians. HP assumes you are qualified in the servicing of
computer equipment and trained in recognizing hazard in products with hazardous energy
levels and are familiar with weight and stability precautions for rack installations.
Technician Notes
WARNING: Only authorized technicians trained by HP should attempt to repair this
equipment. All troubleshooting and repair procedures are detailed to allow only
subassembly/module-level repair. Because of the complexity of the individual boards
and subassemblies, no one should attempt to make repairs at the component level or
to make modifications to any printed wiring board. Improper repairs can create a safety
hazard.
WARNING: To reduce the risk of personal injury from electric shock and hazardous
energy levels, do not exceed the level of repairs specified in these procedures.
Because of the complexity of the individual boards and subassemblies, do not attempt
to make repairs at the component level or to make modifications to any printed wiring
board. Improper repairs can create conditions that are hazardous.
WARNING: To reduce the risk of electric shock or damage to the equipment:
• Disconnect power from the system by unplugging all power cords from the power
supplies.
• Do not disable the power cord grounding plug. The grounding plug is an important
safety feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily
accessible at all times.
HP ProLiant ML150 Server Operations and Maintenance Guide vii
HP CONFIDENTIAL Codename: Stone Soup Part Number: 343329-001 Last Saved On: 8/14/03 9:52 AM

HP ProLiant ML150 Specifications

General

Tcase	72.8 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2603V3
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor codename	Haswell
Motherboard chipset	Intel C610
Number of QPI links	2
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	51 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID support	-
HDD interface	Serial ATA
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	16x DIMM
Internal memory	4 GB
Memory clock speed	2133 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card family	NVIDIA
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Chassis type	Rack (1U)
Power supply	550 W
Processor ARK ID	83349
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0

Weight and Dimensions

Depth	620 mm
Width	200 mm
Height	432.6 mm
Weight	22230 g
