HP ProLiant ML150 User Manual

Installing and Configuring
Mass Storage
The HP ProLiant ML150 server comes standard with an IDE CD-ROM and a flexible disk
drive with some configuration of SCSI hard drives. The internal mass storage can hold up to
five SCSI hard drives with cabling provided.
This section describes how to install the internal mass storage devices.
Mass Storage Configuration
Table 2-1 lists the number and types of mass storage devices that may be installed in the HP
ProLiant ML150 server.
Table 2-1: Mass Storage Device Types
Interface Types Max Number
of Devices
Installed Devices and Addresses
Flexible disk drive 1 Factory installed flexible disk
Primary IDE 1 Factory installed CD-ROM drive (IDE connector)
Ultra-320 SCSI
Channel A
up to 15 * Control of up to 15 external SCSI devices
Ultra-320 SCSI
Channel B
up to 5* Up to 5 SCSI hard drives (addresses = ID 0, 1, 2, 3, 8)
Embedded SCSI controller (address = ID 7)
*Both SCSI channels (A and B) can each support up to 15 devices; however, there are only
enough internal storage shelves for five hard drives and one optional tape backup device.
Channel A is used to control external SCSI devices or internal backup tape.
Guidelines
General Guidelines
•
•
•
•
Be careful when unpacking and handling the disk drives.
The hard drives are very susceptible to mechanical shock and can be easily damaged by a
drop as short as one-quarter of an inch. If the drop would crack an egg, it will damage the
drive.
Do not stack drives.
Do not use high voltage differential (HVD) SCSI devices on any of the SCSI channels or
damage will occur. Use only Single-Ended (SE) or Low-Voltage Differential (LVD)
devices.
The server is internally limited to 5 hard drives.
The flexible disk drive and CD-ROM drive, which are standard on all models of the HP
ProLiant ML150 server, occupy shelves 8 and 7 respectively. Refer to Figure 2-5 and
Figure 2-6
HP ProLiant ML150 Server Operations and Maintenance Guide 2-5
HP CONFIDENTIAL Codename: Stone Soup Part Number: 343329-001 Last Saved On: 8/14/03 10:09 AM

HP ProLiant ML150 Specifications

General

Tcase	72.8 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2603V3
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor codename	Haswell
Motherboard chipset	Intel C610
Number of QPI links	2
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	51 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID support	-
HDD interface	Serial ATA
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	16x DIMM
Internal memory	4 GB
Memory clock speed	2133 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card family	NVIDIA
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Chassis type	Rack (1U)
Power supply	550 W
Processor ARK ID	83349
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0

Weight and Dimensions

Depth	620 mm
Width	200 mm
Height	432.6 mm
Weight	22230 g
