HP ProLiant ML150 User Manual

Controls and Indicators
Applying Power to the HP Server
Powering Up the Server
1. Turn on power to the monitor connected to the HP server.
Turning on the monitor first ensures that video output auto-configures properly as the
server boots up.
2. Press the power switch on the front control panel.
When you press the power switch, the server powers up and loads the operating system.
The system runs a set of power-on self tests (POST) during this process. For details refer
to Chapter 4, “Troubleshooting.”
Powering Down the Server
1. Log off all users and, if necessary, back up files.
— Schedule the power down for a time when the server being down will affect the
fewest users.
— If you will be performing a hardware or software upgrade, be sure the server's data
has been backed up.
— Follow instructions in your network operating system (NOS) documentation to shut
down all networking software and applications.
WARNING: The power supply will continue to provide standby current to the HP server
until the power cable is disconnected from the rear panel.
2. Press the power switch on the HP server's control panel when prompted by the operating
system.
Normally this completes the power-down procedure.
Connecting Power to Multiple-Server Configurations
The HP server temporarily draws a large “inrush current” when first connected to an AC
power source. The inrush current is much greater than the server's normal operating current
and generally, the AC power source can handle the normal inrush current.
1-4 HP ProLiant ML150 Server Operations and Maintenance Guide
HP CONFIDENTIAL Codename: Stone Soup Part Number: 343329-001 Last Saved On: 8/14/03 10:01 AM

HP ProLiant ML150 Specifications

General

Tcase	72.8 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2603V3
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor codename	Haswell
Motherboard chipset	Intel C610
Number of QPI links	2
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	51 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID support	-
HDD interface	Serial ATA
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	16x DIMM
Internal memory	4 GB
Memory clock speed	2133 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card family	NVIDIA
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Chassis type	Rack (1U)
Power supply	550 W
Processor ARK ID	83349
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0

Weight and Dimensions

Depth	620 mm
Width	200 mm
Height	432.6 mm
Weight	22230 g
