HP ProLiant ML150

Specifications
Hardware Specifications
Processors Intel Xeon (up to 2 processors), supported speeds: 2.4 GHz and above, 512 K
level 2 or 1 M level 3 cache on processor
Chipset Intel E7501 chipset with 533 MHz bus speed support
Memory Up to six PC2100 266 MHz ECC registered DDR DIMMs for a maximum total of
12 GB. Supported DIMM types: 256 MB, 512 MB, 1 GB, and 2 GB
Video Embedded ATI Rage XL chip video with 8 MB SDRAM
SCSI Embedded Adaptec AIC-7902 SCSI dual channel controller; 320 MB/s transfer
rate with two 68-pin connectors
IDE Embedded Enhanced-IDE dual channel controller
LAN Embedded Intel 82545EM 10/100/1000 PCI Fast Ethernet Controller; with Wake-
on-LAN enabled/disabled via BIOS setup
PCI Bus Five slots: one 32-bit slot at 33 MHz; two PCI-X 64-bit slots at 66 MHz, two PCI-X
64-bit slots at 66/100/133 MHz
I/O One Serial port and one bi-directional parallel port with ECP/EPP high-speed
support; PS/2 style mouse and keyboard connectors; two USB ports
CD-ROM 5.25-inch optical device; IDE interface
Flexible Disk
Drive
3.5-inch device
