Installing and Configuring
Guidelines
The following sections provide guidelines for installing PCI accessory boards into the HP
ProLiant ML150 server.
Boot Priority
The server’s boot order should be considered when selecting a boot device. This is especially
important if you are installing a board that requires a higher priority in the boot order. The
board's boot priority is set by its slot location in the boot order.
By default the server searches for boot devices in this order:
1. Flexible disk drive
2. IDE CD-ROM drive
3. Embedded SCSI B channel (SCSI drives)
4. Embedded LAN
Using the PCI Bus
The HP ProLiant ML150 server has four 64-bit PCI-X buses, dispatched on a primary and a
secondary channel. The four 64 bit PCI-X busses are peer-to-peer, which provides
approximately equal performance. The fifth PCI slot is a 32-bit PCI bus, which is compliant
with standard PCI 2.2. Refer to Table 2-2.
Table 2-2: PCI Bus Selection.
PCI Slots PCI Bus
Slots 1 and 2* Secondary PCI Bus (66 MHz PCI-X)
Slots 3 and 4 Primary PCI Bus (66/100/133 MHz
PCI-X)
Slots 5 32-bit PCI
*ZCR (Zero Channel RAID) cards must be inserted in the PCI slot 2
(green color). .
HP ProLiant ML150 Server Operations and Maintenance Guide 2-27
HP CONFIDENTIAL Codename: Stone Soup Part Number: 343329-001 Last Saved On: 8/14/03 10:09 AM

HP ProLiant ML150 Specifications

General

Tcase	72.8 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor cache	15 MB
Processor cores	6
Processor model	E5-2603V3
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor codename	Haswell
Motherboard chipset	Intel C610
Number of QPI links	2
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600 MHz
Memory bandwidth supported by processor (max)	51 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID support	-
HDD interface	Serial ATA
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	16x DIMM
Internal memory	4 GB
Memory clock speed	2133 MHz
Maximum internal memory	256 GB
Memory layout (slots x size)	1 x 4 GB
Graphics card family	NVIDIA
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Chassis type	Rack (1U)
Power supply	550 W
Processor ARK ID	83349
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
PCI Express slots version	3.0

Weight and Dimensions

Depth	620 mm
Width	200 mm
Height	432.6 mm
Weight	22230 g
