HP ProLiant ML150

Installing and Configuring
Figure 2-17: Mounting heatsink brackets
5. Open the locking levers on both brackets by pulling the lever out away from the
processor socket and rotating it to the vertical position. Then, position the heatsink
between the brackets on the processor. Refer to Figure 2-18.
Figure 2-18: Positioning heatsink
2-24 HP ProLiant ML150 Server Operations and Maintenance Guide
