HP ProLiant ML150

Installing and Configuring
7. Identify the accessory slot number to be used. Refer to Figure 2-21. (An ZCR RAID card
must be inserted in PCI slot 2 (green color).)
Figure 2-21: Accessory slots
Item Description
1 PCI slot 1
2 PCI slot 2
3 PCI slot 3
4 PCI slot 4
5 PCI slot 5
8. Push the PCI slot cover from the rear of the chassis and slide it towards you to remove it.
Refer to Figure 2-22.
NOTE: Be sure you save the slot covers for use later to prevent EMI interference.
2-30 HP ProLiant ML150 Server Operations and Maintenance Guide
HP CONFIDENTIAL Codename: Stone Soup Part Number: 343329-001 Last Saved On: 8/14/03 10:09 AM
