Item Description
1 PCIe3 x16 slot 1 for low-profile, standup expansion board or riser cage options
1
2 microSD card slot
3 PCIe3 x24 slot 2 for low-profile, standup expansion board, riser cage option, or NVMe pass-through board
1
4 TPM 20 connector
5 Flexible Smart Array Controller slot
6 PCIe3 x8 slot 5 for low-profile, standup expansion board
2
7 System maintenance switch
8 PCIe3 x24 slot 6 for low-profile, standup expansion board, riser cage options, or NVMe pass-through board
2
9 PCIe3 x16 slot 7 for low-profile, standup expansion board or riser cage options
2
10
Controller backup power connectors for expansion slots 3-7
11 Front LED connector
12 Processor 2 DIMM slots
13 System battery
14 Processor 1 DIMM slots
15 Fan signal connector
16 Energy pack connector
17 Fan power connector
18 Internal drive cage backplane power connector
19 Controller backup power connectors for expansion slots 1-2
20 Front drive cage backplane power connector
21 Power supply backplane connector
22 Rear drive cage backplane power connector
23 Rear 6SFF NVMe drive cage fan connector
24 Mini SAS connector 1
25 SATA connector 2
26 SATA connector 1
27 Internal USB 30 port
28 Front USB 20 port
1
The PCIe3 expansion slots 1-2 are associated with processor 1.
2
The PCIe3 expansion slots 5-7 are associated with processor 2.
DIMM slot locations
DIMM slots are numbered sequentially (1 through 8) for each processor. The supported AMP modes use the letter
assignments for population guidelines.
Component identification
153
