Replacing the Pensando DSP DSC-25 2p SFP28 card
Pensando DSP iLO Sideband ALOM Module requires that the accompanying Smart I/O card ( Pensando DSP DSC-252p SFP28
card) be installed on slot 1 of the primary PCIe riser cage.
NOTE: Images might dier from the actual product.
Procedure
1.
Install the DSC-25 card into the PCIe slot:
2.
Install the PCIe riser cage into the server.
CAUTION: Do not twist the cable service loop during installation.
Removal and replacement procedures 79
