HPE Apollo 4200 Gen10

Components
Item Description
1 Internal SAS port 1i
2 Internal SAS port 2i
3 Internal SAS port 3i
4 Internal SAS port 4i
5 Controller backup power cable connector
6 Internal SAS port 5i
7 Internal SAS port 6i
HPE InfiniBand HDR/Ethernet 940QSFP 56x16 adapter LEDs
Link LED status
1
Description
O A link has not been established.
Solid amber Active physical link exists
Blinking amber 4 Hz blinking amber indicates a problem with the physical
link.
Solid green A valid logical (data activity) link exists with no active traic.
Blinking green A valid logical link exists with active traic.
1
2-port adapter LEDs are shown. The 1-port adapters have only a single LED.
Component identification 172
