HPE Apollo 4200 Gen10

Item Drive numbering
Internal drive cage 49, 50, 51, 52
HPE Smart Storage
S100i SR Gen10
controller (RAID)
49, 149, 50, 150
HPE Smart Storage
S100i SR Gen10
controller (HBA mode)
1, 2, 3, 4
Directly attached to
controller
49, 149, 50, 150
6SFF NVMe rear drive numbering
6SFF rear drive numbering (SAS, SATA)
Drive LEDs
LFF, SFF, NVMe, and uFF drives have dierent sets of LEDs to reflect the drive status.
Low-profile LFF drive LED definitions
