HPE Apollo 4200 Gen10

Illustrated parts catalog
Mechanical components
Hewlett Packard Enterprise continually improves and changes product parts. For complete and current supported parts
information, see the Hewlett Packard Enterprise PartSurfer website (http://www.hpe.com/info/partssurfer).
Item Description
1
Air bale spare part
2
Fan cage spare part
3
Fan spare part
4
Cable management holder spare part
5
Miscellaneous mechanical spare parts
5a: Air blocker for the onboard PCIe expansion slots 5-7
5b: Chassis retention bracket
5c: SFF drive blank
Table Continued
