Item Description
5 Storage controller or NVMe pass-through board connector
6 Mezzanine connector 1 (Type A mezzanine only)
7 Mezzanine connector 2 (Type A or Type B mezzanine)
8 Enclosure connector
9 FlexibleLOM connectors (2)
10 SAS/SATA or NVMe backplane
11 Internal USB 3.0 connector
12 Energy pack connector
13 Direct-connect SATA connector
14 System maintenance switch
15 microSD card slot
16 TPM connector
System maintenance switch
Position Default Function
S1 Off
Off = iLO security is enabled.
On = iLO security is disabled.
S2 Off
Off = System configuration can be changed.
On = System configuration is locked.
S3 Off Reserved
S4 Off Reserved
S5 Off
Off = Power-on password is enabled.
On = Power-on password is disabled.
S6 Off
Off = No function.
On = ROM reads system configuration as invalid.
S7 Off Reserved
S8 — Reserved
S9 Off Reserved
S10 — Reserved
S11 — Reserved
S12 — Reserved
14 Component identification
