Install the front panel/drive cage assembly
Prerequisites
To install the front panel/drive cage assembly, you need a T-15 Torx screwdriver.
Procedure
1. Install the front panel/drive cage assembly:
a. Extend the serial label pull tab from the front of the server blade.
b. Align the pins on the chassis and slide the front panel/drive cage assembly into the server blade.
c. Secure the assembly with two T-15 screws.
d. Close the serial label pull tab.
Operations 37
