2. Press the Do Not Remove button to release the Release lever.
3. Install the drive.
4. Determine the status of the drive.
For more information, see the NVMe SSD components on page 10.
Installing the SFF Flash Adapter option
CAUTION: To prevent improper cooling and thermal damage, do not operate the server blade or the
enclosure unless all device bays are populated with either a component or a blank.
Prerequisites
To support uFF drives and the SFF Flash Adapter option, install the SAS/SATA HDD backplane with one
of the following:
• Direct connect SATA cable
• HPE Smart Array P204i SR Gen10 Controller
Procedure
1. Remove the drive blank.
Hardware options installation 47
