Install the DIMM baffles
The server has two DIMM baffles.
Procedure
1. Align and install the DIMM baffle:
IMPORTANT: When installing each DIMM baffle, be sure that the alignment tabs engage with
the side of the server blade.
• DIMM baffle (right side)
• DIMM baffle (left side)
Operations 25
