Prerequisites
Before installing this option, be sure that you have the following the components included with the
hardware option kit.
For more information on specific options, see the server blade QuickSpecs on the Hewlett Packard
Enterprise website (http://www.hpe.com/info/qs).
Procedure
1. Power down the server blade on page 21.
2. Remove the server blade on page 22.
3. Place the server blade on a flat, level work surface.
4. Remove the access panel on page 22.
IMPORTANT: When removing a DIMM baffle, do not remove the following options when
installed on the DIMM baffle:
• M.2 enablement option (left DIMM baffle)
• HPE Smart Storage Battery (right DIMM baffle)
5. Remove the DIMM baffles on page 23.
6. Open the appropriate DIMM slot latches.
7. Install the DIMM.
8. Install the DIMM baffles on page 25.
9. Install the access panel on page 23.
10. Install the server blade on page 42.
11. Power up the server blade on page 21.
To configure the memory mode, use the BIOS/Platform Configuration (RBSU) in the UEFI System
Utilities.
Hardware options installation 61
