4. Do one of the following:
• If the new Smart Array is the new boot device, install the device drivers.
• If the new Smart Array is not the new boot device, go to the next step.
5. Ensure that users are logged o and that all tasks are completed on the server.
CAUTION: In systems that use external data storage, be sure that the server is the first unit to be powered down
and the last to be powered back up. Taking this precaution ensures that the system does not erroneously mark the
drives as failed when the server is powered up.
Procedure
1.
Power down the server.
2. Disconnect the power cord from the AC source.
3. Remove the power adapter cord from the power cord clip, and then disconnect the power adapter from the server.
4. Disconnect all peripheral cables from the server.
5.
If installed, unlock and remove the security padlock and/or the Kensington security lock.
For more information, see the lock documentation.
6.
If the server is in a vertical orientation, position the server in a horizontal orientation.
7. Remove the chassis cover.
8. Remove the system board assembly.
9. If the storage controller board is shipped with a full-height bracket attached,
replace it with a low-profile one.
10. Remove the expansion slot blank.
46
Hardware options installation
