HPE ProLiant MicroServer Gen10 Plus User Manual

Retain the blank for future use.
11. Install the storage controller. Make sure that the storage controller is firmly seated in the slot.
12.
Cable the controller.
13.
Install the server board assembly.
14.
Install the chassis cover.
15.
If removed, install the security padlock and/or the Kensington security lock.
For more information, see the lock documentation.
16.
Connect all peripheral cables to the server.
17.
Connect the power adapter to the server, and then secure the power adapter cord in the power cord clip.
18. Connect the power cord to the AC source.
19.
Configure the storage controller.
The installation is complete.
Configuring an HPE Smart Array Gen10 controller
Procedure
1.
Power up the server.
2. If you are running the server in UEFI Boot Mode, select the boot options.
Hardware options installation
47

HPE ProLiant MicroServer Gen10 Plus Specifications

General

Processor Cores	4
Memory Slots	2
Network	2 x 1GbE ports
Processor	Intel Xeon E-2224
Processor Base Frequency	3.4 GHz
Storage	4 LFF SATA HDD bays
Storage Controller	Embedded SATA controller
Expansion Slots	1 PCIe 3.0 x16 slot
Form Factor	Ultra-micro tower
Remote Management	HPE iLO 5
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, VMware ESXi
Dimensions	22.97 x 24.5 x 24.5 cm (8.98 x 9.65 x 9.65 in)
