Component identification
This chapter describes the external and internal server features and components.
Front panel components
Item Component Description
1 Drive bays (4, behind the front bezel) By default, the drive bays support 35-inch LFF SATA drives.
To support 25-inch SFF drives, install the SFF drive converter
option.
2 Front bezel To access the drive bays, remove this bezel.
3 USB 32 Gen 2 Type-A ports
1
Connect USB devices. These ports are backwards compatible with
earlier USB Type-A version devices.
1
These ports are also known as SuperSpeed USB 10 Gb/s ports. The appropriate cable and compatible hardware are required to take
advantage of the 10 Gb/s data transfer speed.
6 Component identification
