2. Install the retaining latch at the 80 mm drive location.

Removing and replacing an internal USB deviceRemoving and replacing an internal USB device

ProcedureProcedure

1. Power down the server.

2. Remove all power:

HPE ProLiant ML30 Gen10 Plus Server Maintenance and Service Guide 107
