Fan numberingFan numbering
Fan numberFan number DescriptionDescription
1 PCI fan (optional)
2 System fan
3 Heatsink fan
Fan mode behaviorFan mode behavior
The server supports nonredundant fan mode. If a fan fails or is missing, the following behaviors are exhibited:
The health LED flashes red.
The operating system performs a graceful shutdown.
Media device screwsMedia device screws
There are eight T-15 Torx screws on the front panel. These screws are spare screws for installing media devices.
