7. Disconnect the power and USB cables.
8. Pull up and hold the release latch (callout 1), and then remove the RDX docking station (callout 2).
ResultsResults
To replace the component, reverse the removal procedure.
Removing and replacing an optical driveRemoving and replacing an optical drive
PrerequisitesPrerequisites
Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
ProcedureProcedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Disconnect all peripheral cables from the server.
4. Do one of the following:
If the server is in tower mode, place the server on a flat, level surface with the access panel facing up.
