ResultsResults
To replace the component, reverse the removal procedure.
Removing and replacing the air baffleRemoving and replacing the air baffle
About this taskAbout this task
CAUTION:CAUTION: For proper cooling, do not operate the server without the access panel, baffles, expansion slot covers, or blanks
installed. If the server supports hot-plug components, minimize the amount of time the access panel is open.
ProcedureProcedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Disconnect all peripheral cables from the server.
4. Do one of the following:
If the server is in tower mode, place the server on a flat, level surface with the access panel facing up.
