ItemItem DescriptionDescription
1 Flexible Slot power supply 1 (hot-plug)
2 Flexible Slot power supply 2 (hot-plug)
3 Non-hot-plug power supply
4 Power cord clip (for non-hot-plug power supply)
5 Padlock eye
6 Kensington security slot
7 Slot 4 PCIe3 x8 (4, 1)
8 Slot 3 PCIe3 x16 (4, 1)
9 Slot 2 PCIe3 x8 (4, 1)
10 Slot 1 PCIe4 x16 (16, 8, 4, 1)
11 iLO dedicated network port (optional)
12 NIC port 2 (1 GbE)
13 USB 3.0 ports
14 NIC 1 / iLO shared port (1 GbE)
15 Video port
16 Serial port (optional)
Rear panel LEDsRear panel LEDs
