ItemItem Cable labelCable label ConnectionConnection
1 HDD PWR (PDB) Connects to RPS power distribution board
2 ODD PWR Connects to the optical drive
3 P4 Connects to the LTO/RDX power extension cable
4 LTO PWR LTO/RDX power connector
5 P2 Connects to the LTO/RDX power extension cable
6 NHP PWR Connects to the SATA-power splitter cable in the 4 LFF non-
hot-plug drive configuration
7 BP HP PWR Connects to the 4 LFF / 8 SFF hot-plug drive backplane
SpecificationsSpecifications
SubtopicsSubtopics
Environmental specificationsEnvironmental specifications
Mechanical specificationsMechanical specifications
Power supply specificationsPower supply specifications
Environmental specificationsEnvironmental specifications
SpecificationsSpecifications ValueValue
Temperature range*Temperature range* —
Operating 10°C to 35°C (50°F to 95°F)
Nonoperating -30°C to 60°C (-22°F to 140°F)
Relative humidity (noncondensing)Relative humidity (noncondensing) —
Operating 8% to 90%
28°C (82.4°F) maximum wet bulb temperature, noncondensing
Nonoperating 5% to 95%
38.7°C (101.7°F) maximum wet bulb temperature, noncondensing
AltitudeAltitude —
Operating 3050 m (10,000 ft)
This value may be limited by the type and number of options installed. Maximum allowable
altitude change rate is 457 m/min (1,500 ft/min).
Nonoperating 9144 m (30,000 ft)
Maximum allowable altitude change rate is 457 m/min (1,500 ft/min).
Standard operating supportStandard operating support
10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1,000 ft) above sea level to a
maximum of 3,050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 20°C/hr (36°F/hr). The upper limit and rate of
