ColorColor Mini-SAS splitter cable connectionMini-SAS splitter cable connection
Orange Drive backplane
Blue Drive backplane sideband connector
Gold Onboard SATA port 1
Pink Onboard SATA port 4
Green Onboard SATA port 3
Black Onboard SATA port 2
4 LFF hot-plug drive: Type-p controller cabling4 LFF hot-plug drive: Type-p controller cabling
8 SFF hot-plug drive: Type-p controller cabling8 SFF hot-plug drive: Type-p controller cabling
