7. MEM - STORAGE OF RESULTS
The instrument can store up to up to 9999 measurement results (I-V curves or IVCK tests).
Test results can be organised and grouped in a structure similar to that of the photovoltaic
system being tested by associating up to 3 different levels of markers for each of the
memory locations used, in order to detail the corresponding location of the measurement.
For example, a location tested as 'Plant XX', 'String YY', 'Module ZZ' can be stored and
associated with the measurement just taken.
7.1. SAVING MEASURES
1. With the measurement on the display, tap on the icon to save. When saving for
the first time (empty memory), a first-level marker must be defined and the
following screen will be displayed
Fig. 62: Saving Measurement Result - Step 1
2. Tap on the key to confirm. The following screen will be displayed:
Fig. 63: Saving Measurement Result - Step 2
3. The instrument shows a list of possible pre-defined markers. Use the virtual
alphanumeric keyboard to define a new marker string (ex: "PLANT A") and touch the
(ENTER) button to confirm. The name will appear in the list of markers highlighted
in blue, as shown in the following figure.
