6.2. SOLAR03 - REMOTE UNIT
The SOLAR03 remote unit allows measuring the Irradiance and temperature values of the
module, which are indispensable for the evaluation of the I-V curve, as well as the IVCK
with values referenced to @STC. In general, the instrument and the SOLAR03 unit can
operate in direct connection or synchronous recording.
The maximum direct connection distance between the SOLAR03 unit and the instrument
may vary depending on the obstacles between the two units and if the distance between
the SOLAR03 unit and the instrument is up to 100m (328ft) in free air conditions. In the
presence of obstacles, the synchronous recording mode is to be preferred.
This section manages all the operations that can be performed on the SOLAR03 remote
unit in conjunction with the instrument. In particular, it is possible to:
➢ Using the Bluetooth connection, find a SOLAR03 remote unit that can be managed
by the instrument by entering it in its internal list.
➢ Select or cancel a remote unit SOLAR03 among those present in the list;
➢ Pair/unpair a remote unit SOLAR03 to/from the instrument so that it can be
automatically recognized upon every connection;
➢ Display the information of the selected remote unit.
➢ Activate/stop recording environmental parameters (temperature/irradiance) on a
connected and active remote unit.
In particular, for each managed SOLAR03 remote unit, the instrument provides the
following information:
➢ Serial Number
➢ Active (symbol ) or inactive (no symbol) remote unit
➢ Active remote unit connected to the instrument
➢ Active and connected unit in recording mode ('Rec.' symbol)
Pairing a Remote Unit
1. Switch on the instrument using the ON/OFF key
2. Tap on the "SOLAR03” icon on the main menu. The following screen will be displayed
Fig. 15: Pairing a SOLAR03 remote unit - Step 1
