10. TECHNICAL SPECIFICATIONS
10.1. TECHNICAL CHARACTERISTICS
Accuracy stated as ± [%reading + (num. dgt*resolution)] at 23 °C ± 5 °C, <80%RH
MULTIMETER FUNCTION
DMM – DC Voltage
Range [V]
Resolution [V]
Accuracy
3  1500
1
(1.0reading + 2dgt)
I-V CURVE MEASUREMENTS AND IVCK TESTS
I-V, IVCK: DC Voltage (@ OPC)
Range [V]
Resolution [V]
Accuracy (*)
15.0  1500.0
0.1
(0.2%Voc)
(*) In accordance with IEC/EN60904-1; Measurements start at VDC > 15V and with module capacitance <30µF
I-V, IVCK: DC Current (@ OPC)
Range [A]
Resolution [A]
Accuracy (*)
0.20  40.00
0.01
(0.2%Isc)
(*) In accordance with IEC/EN60904-1; Iscmin = 0.2A and module capacitance <30µF
I-V: DC Power (@ OPC) (VDC > 30V)
Range [W] (*)
Resolution [W]
Accuracy (*)
50  9999
1
(1.0 reading + 6dgt)
10.00k  99.99k
0.01k
(*) VDC voltage ≥ 30V and module capacitance <30µF
(**) Max. measurable power must also consider a max. FF of 0.7 → Pmax= 1500V x 40A x 0.7 = 42.00kW
I-V, IVCK: DC Voltage (@ STC)
Range [V]
Resolution [V]
Accuracy
3.0  1500.0
0.1
4.0 reading + 2dgt)
I-V, IVCK: DC Current (@ STC)
Range [A]
Resolution [A]
Accuracy
0.20  40.00
0.01
4.0 reading + 2dgt)
I-V: DC Power @ STC (referred to 1 module)
Range [W]
Resolution [W]
Accuracy
50  9999
1
(4.0reading + 2dgt)
Module capacitance <30µF
