10.2. GENERAL CHARACTERISTICS
Reference guidelines
Instrument safety: IEC/EN61010-1, IEC/EN61010-2-030
EMC: IEC/EN61326-1
Technical literature: IEC/EN61187
Safety of measuring accessories: IEC/EN61010-031
Measurements: IEC/EN60891, IECEN60904-1-2 (I-V curves)
IEC/EN62446, IECEN60904-1-2 (IVCK test)
Radio: ETSI EN300328, EN301489-1, EN301489-17
Insulation: double insulation
Level of pollution: 2
Measurement category: CAT III 1500VDC, max. 1500VDC between inputs
Display, memory and PC interface
Type of display: TFT colour, 7", capacitive touch screen, 800x480pxl
Memory type: Memory card, max. 32GB (non-expandable)
Internal database: ca 63.000 modules can be saved
Saved data: 9999 IVCK tests or I-V curve
PC interface: USB-C and WiFi
Interface with SOLAR03: Bluetooth connection (up to 100m/328Ft free space)
Power supply
Internal power supply: 8x1.5V type AA LR06 alkaline batteries or
8x1.2V type AA rechargeable NiMH batteries
External power supply: 100-440VAC/15VDC, 50/60Hz external power supply
CAT IV 300V (use HT power supply only)
Battery charging algorithm: via P1, C1, P2, C2 inputs
Battery Management System (BMS): energy recovered from I-V curve measurements
Consumption: 8W
Low battery indication: symbol “ “ is displayed
Charging time: approx. 4 hours
Battery life (@ 0 °C to 40 °C): 8 hours under the following conditions:
➢ Battery capacity: 2000mAh
➢ PV string voltage: 800V
➢ Work cycles: 80 measurements/hour
➢ Instrument connected for 30s/measurement
➢ Instrument disconnected for 15s/measurement
Auto power off: 1 ÷ 10min selectable (can be disabled)
Mechanical characteristics
Dimensions (L x W x H) 336 x 300 x 132mm (13 x 12 x 5in)
Weight (batteries included): 5.5 kg (11lv)
Mechanical protection: IP40 (case open), IP67 (case closed)
