HUAWEI TE80 Videoconferencing Endpoint
Administrator Guide
B Technical Specifications
Issue 02 (2014-03-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
155
Catego
ry
Item
Specifications
Audio
Input
2 x XLR, 2 x RCA, 1 x microphone array HD-AI port,
1 x HDMI port (supporting audio input), and 1 x
DisplayPort (supporting audio input)
Output
4 x RCA port, 2 x HDMI port (supporting audio output),
and 2 x DVI-I (output using DVI-HDMI conversion
cables)
Audio processing
AEC, ANS, and AGC
Networ
k port
Network port
2 x 10/100/1000 M LAN, 1 x Wi-Fi, 1 x 4 E1 connector
(optional, only for the TE80), and 1 x PSTN (Only
available in China)
USB
port
USB
2 × USB 2.0
COM
port
COM
2 × COM
Periphe
rals
VPC600 and VPC620 HD cameras
Endpoint control by using the camera to forward infrared signals
The endpoint supports up to 30 and 16 camera presets for the local site and
remote site respectively.
VPM220 and VPM220W microphone arrays
The TE40 and TE50 can be connected to only one VPM220 or VPM220W
microphone array. The TE80 can be connected to up to two VPM220 or
VPM220W microphone arrays.
Electric
ity
supply
require
ments
Operating voltage
and frequency
100 V AC–240 V AC; 50 Hz–60 Hz;
Maximum power
consumption
150 W
Environ
mental
require
ments
Operating state
Ambient
temperature
0°C to 40°C (32°F to 104°F)
Relative humidity
10% to 80%
Ambient noise
< 46 dBA SPL
Minimum
illuminance
7lux
Recommended
illuminance
> 300 lux
Non-operating state
Ambient
–40°C to +85°C
